Sensoco Loomair M is a high-quality optical IoT sensor which uses the non-dispersive infrared (NDIR) method to measure the carbon dioxide (CO2 ) concentration in airconditioned buildings.
Loomair M.
M for Mobile.
Sensoco Loomair M is an advanced and versatile 3-in-1 transmitter designed for installation in the air-conditioned zone. It measures CO2 concentration, temperature and humidity in the ambient air accurately without need for additional compensation – true read. The data transmits to a BMS system or stand-alone controller using industry standard output signals and communication protocols.
Loomair M combines all the necessary elements for effective climate control in commercial office buildings, hospitals, hotels, schools and other facilities. Using CO2- monitoring for demand control ventilation (DCV) allows healthy, comfortable and cost-effective environment for the occupants. It is flexible in design with temperature control and combination of humidity control optional. Though suitable for use in many different energy- efficient ventilation strategies, Senseair welcomes any discussions for specific needs.
Complies with ASHRAE standard 189.1 (±50ppm @ 1000ppm of measured CO2 value).
-
• Maintenance free
• 4 sensors in one housing
• Battery-powered
• IoT connected using the market’s leading radio interfaces • Indoor air quality indication on display as well as
intuitive LEDs
• Remote indoor air quality monitoring through the cloud-
based web portal or app -
Standard: BLE, Bluetooth 4.2 low energy, Tx power +8dBm, Rx Sensitivity -90 dBm, range up to 200 m
Optional: Sigfox (EU) + LoRaWAN (EU)
Technical Specifications
• Measured gas: Carbon Dioxide CO2
• Measurement range: 400 – 5000ppm
• Sensor Type: Non-dispersive infrared (NDIR)
• Accuracy (CO2 ): +/- 30ppm +/- 3% of reading
• Digital Temperature & Humidity Sensor
• Communication Network: SIGFOX 1 EMAEI
• Option SIGFOX ZONE 2,4 AMERICAS / APAC
• Worlwide Network Access via API
• Operating Frequency: 868.130 MHz
• Transmission Cycle: max. 6 / hour or less
• Option: Dual Radio Version
• Option: LoRaWAN, wireless Mbus, KNX
• Antennas: 2 internal for dual radio applications
• Dashboards: available from GREATECH
• Optical LED display: Limits acc. to DIN EN13779
• Operating Temperature Range: -20°C to +50°C
• Power Supply: external 5V DC / 24V DC
• Dimensions: 120 x 70 x 25 mm
Sensoco Loomair M is a wireless CO2-, temperature- and humidity-sensor, build for mobile usage. The device has an advanced and versatile 4-in-1 IAQ monitor that is easy to read in any environment. It measures CO2 concentration, temperature, humidity and barometric pressure in the ambient air accurately without need for additional compensation – true read. The measured parameters are conveniently combined into one common indicator – the Sensoco Index – describing how your performance is affected by the ambient air. Research shows that the air around us significantly affects our health and performance. Loomair M puts you in control of the surrounding environment and secures your top performance.
Thanks to the ultra-low power sensor, the Loomair M is possible to run on batteries for at least 2 years, depending on the actual configuration. The measured data is shown on a high resolution display and the overall indoor air quality is intuitively indicated by the highly visible LED elements. The data is wirelessly transmitted using an open protocol and can be viewed using a laptop dashboard or a smart phone app.
The product complies with ASHRAE standard 189.1 (±50ppm @ 1000ppm of measured CO2 value).
Measured gas: Carbon dioxide CO2
Measurement range CO2: 400–5,000 ppm
Temperature: -40 - 85°C
Relative Humidity: 0 - 85%
RHVOC (Option): 0-500 IAQ
Accuracy (CO2): ±30ppm ±3% of reading
Dimensions: 148mm x 58mm x 29mm
Life expectancy: <15 years (battery 2 years)
Operation temperature range: 0 - 50°C
Power supply: 2x industrial AA Lithium batteries (included)
Communication: BLE and LoRa (option)
Price includes: 1 x Sensoco Loomair M IoT CO2 sensor (made in Europe), 2 x AA batteries exclusive
