If you require quantities smaller than one reel, please contact us so that we can guide you through the purchasing process. Due to standardized manufacturing processes, we mainly supply complete reels to end customers.
The hybrid module SJIT LSM110A combines the best and most widely used IoT technologies in the world under one hood: Sigfox and LoRaWAN/P2P + ST Microcontroller. Your product is instantly Sigfox or LoRaWAN ready. The SJI LSM110A from Seong Ji is for the regions RC2 and RC4. For RC1 (Europe) please choose SJI LSM100A.
Features
CE & FCC certified
Size : 14.0mm * 15.0mm * 2.8mm
Sigfox RC2 & RC4, LoRaWAN [US902-928, AU915-928, AS923-1]
AT Version & API Version
Very Low Power Consumption
Output power 22 dBm
The RC1882CEF-MIOTY module is a compact surface-mounted product that measures only 12.7 x 25.4 x 3.7 mm. The module contains a communication controller with embedded MIOTY protocol software and is pre-certified for operation under the European regulations. Custom variants can be offered with custom functionalities.
Applications:
• LPWAN • Smart City • Long range sensor applications • Industry 4.0
Features:
• MIOTY compatibility (IOT) • ETSI technical specification TS 103 357 Low Throughput Network (LTN) • Long range, high reliability • Ultra narrowband, high-performance radio • High sensitivity and high selectivity • High blocking properties • Completely shielded module • Pin compatible with other products from Radiocrafts • 12.7 x 25.4 x 3.7 mm compact module for SMD mounting • 2.0 – 3.6 V supply voltage • Ultra low power modes • Conforms with EU RED directive (EN 300 220, EN 301 489, EN 60950)
What is Sensoco® Modbus RTU Bridge?
Sensoco® Modbus RTU Bridge is a universal system component for connecting all types of measuring devices and sensors with RS485 Modbus RTU protocol. Applications such as smart metering or the measurement of pressure, flow, temperature, gas concentration, position, etc. are possible. The data from the connected devices can be read out and transmitted wirelessly.
What are the main features?
Mioty Modbus Bridge
RS485 interface
Modbus RTU protocol
UART data rate: Standard 9600 bps
Option: Baud rate selector switch
Number of slaves: 1 to 10
LTN telegram division: Ultra Narrowband
ETSI Technical Specification TS 103 357
Supports modes EU0, EU1, EU2, US0
RF power: 14 dBm
Operating frequency: 868 MHz and 916 MHz
Data rate: 2380 bits/s
Antenna: SMA socket
Dashboards: Own and available from several providers
Power supply: External 5 V – 24 V DC at 50 mA
Operating temperature range: -20 °C to +50 °C
Housing: Standard DIN rail, 2 modules
Dimensions: 35 x 86 x 58 mm
Manufactured in Germany
What is included?
Sensoco® Modbus RTU Bridge
Antenna
Quick start guide
